| CPU |
Intel Processor 1.6 GHz |
| DRAM |
1GB DDRII RAM |
| Flash
Memory |
128MB DOM |
| HDD |
6 x 3.5" SATA I/II
NOTE:
- The system is shipped without HDD.
- For the HDD compatibility list, please visit
|
| HDD Tray |
6 x Hot-swappable and lockable
tray |
| LAN Port |
2 x Gigabit RJ-45 Ethernet
port |
| LED
Indicators |
Status, LAN, USB, eSATA,
Power, HDD 1, HDD 2, HDD 3, HDD 4, HDD 5, HDD 6, USB, LAN |
| USB |
5 x USB 2.0 port (Front: 1;
Back: 4)
Support USB printer, pen drive, USB hub, and USB UPS etc. |
| eSATA |
2 x eSATA port (Back) |
| Buttons |
System: Power button, USB
One-Touch-Backup Button, Reset button |
| LCD panel |
Mono-LCD display with
backlight
Enter button, Select button for configuration |
| Alarm
Buzzer |
System warning |
| Form
Factor |
Tower |
| Dimensions |
175 (H) x 257 (W) x 235 (D) mm
6.89 (H) x 10.12 (W) x 9.25 (D) inch |
| Weight |
Net weight:
5.2 kg (11.46 lbs)
Gross weight: 6.5 kg (14.33 lbs) |
| Sound
Level (dB) |
w/o HDD installed: 34.1 dB
Stand by: 34.2 dB
In operation: 38.2 dB |
| Power
Consumption (W) |
Sleep mode:
29W
In Operation: 43W
Power-off (in WOL mode): 1W
(with 6 x 500GB HDD installed) |
| Temperature |
0~40°C |
| Humidity |
0~95% R.H. |
| Power
Supply |
Input: 110-240V AC, 50/60Hz,
Output: 250W |
| Secure
Design |
K-lock security slot for theft
prevention |
| VGA |
Reserved VGA interface for
maintenance |
| Fan |
2 x quiet cooling fan (9 cm,
12V DC) |
 |
